Distribution box

XM type distribution box is a carefully designed distribution equipment by Shuangying Electric for end circuits, suitable for Single phase, three wire, or three wire loads with a constant voltage of 220V or 380V and a total current of no more than 80A per row load Phase five terminal circuit. It not only enables precise control and distribution of electrical equipment, but also has the ability to Good line protection function can effectively deal with common circuits such as overload, short circuit, leakage, overvoltage, etc Malfunction, fully ensuring electrical safety. The bottom box of the distribution box is made of high-quality cold-rolled steel plate, and the surface is coated with Spray coating treatment has excellent characteristics of non deformation, non oxidation, and corrosion resistance. At the same time, provide visible decoration There are two installation methods for concealed installation to meet the diverse installation needs of different scenarios.

• GB/T 7251.3-2017《Low voltage switchgear and control equipment - Part 3: Distribution boards operated by general personnel》
• GB/T 16935.1-2020《Insulation coordination of equipment in low-voltage systems - Part 1: Principles, requirements and tests》
• GB 7251.8-2020《Low voltage switchgear and control equipment - Part 8: General technical requirements for intelligent complete sets》
• JB/T 9663-2013《Low voltage reactive power automatic compensation controller》
• DL/T 597-2017《Technical Specifications for Ordering Low Voltage Reactive Power Compensation Controllers》
• JB/T 121-2013《Modular terminal combination electrical appliance》
• IEC 61439-1:2020《Low voltage switchgear and control equipment components - Part 1: General principles》
• IEC 61439-2:2020《Low voltage switchgear and control equipment components - Part 2: Complete sets of power switchgear and control equipment》
• IEC 60831-1:2017《Low voltage power capacitors - Part 1: General principles》

• Good protection: The shell has excellent protection, which can effectively prevent dust, water, and foreign objects from entering, ensuring the safe operation of internal components in various environments.
• Flexible configuration: The internal layout can be flexibly configured according to needs, adapting to different electrical circuits and load requirements, with strong practicality.
• Safe and reliable: Equipped with overload, circuit breaker and other protection functions, it can promptly cut off faulty circuits, ensuring electrical safety and high stability.
• Easy installation: The overall structure is easy to install, with a moderate volume that can adapt to various installation locations, and daily maintenance operations are relatively simple.
