Low Voltage Withdrawable Switchgear Cubicle

GCK type low-voltage withdrawable switchgear is developed by Shuangying Electric for modern industrial and commercial power distribution needs Advanced equipment suitable for AC 50 (60) Hz, rated working voltage 400V and below The control and distribution system. It consists of a power distribution center (PC) cabinet and a motor control center (MCC) Composed of two parts, with clear division of labor and collaborative work, providing precise distribution control for various electrical equipment. The cabinet is made of 8MF steel combination splicing, which not only ensures the strength and stability of the cabinet Sex also makes each functional unit relatively independent, and the propulsion mechanism adopts a lever propulsion mechanism to ensure the same single unit Yuan energy exchange greatly improves the reliability of power supply.

• GB/T 24274-2019《Low voltage withdrawable switchgear and control equipment》
• GB 7251.2-2023《Low voltage switchgear and control equipment - Part 2》
• GB/T 14048.1-2012《Low voltage switchgear and control equipment - Part 1: General principles》
• IEC 60439-1《Low voltage switchgear and control equipment - Part 1: General principles》
• ZBK 36001《Low voltage withdrawable complete switchgear》
• JB/T 9661-1999《Low voltage withdrawable complete switchgear》

• Structural advantages: Adopting a pull-out structure, compact and reasonable, space saving, convenient for component installation, replacement and maintenance, flexible layout.
• Security guarantee: With reliable electrical interlocking and protective measures, it can effectively prevent misoperation, ensure the safety of personnel and equipment, and also deal with faults such as short circuits.
• Reliable performance: High quality components are selected, with stable electrical performance that can adapt to various load conditions, ensuring stable power supply and high reliability.
• Convenient to use: Simple and intuitive operation, easy daily maintenance, easy to carry out repairs, can quickly troubleshoot and handle faults, and reduce downtime.
