Indoor AC metal armored withdrawable switchgear

KYN28-12 indoor AC metal armored withdrawable switchgear is designed by Shuangying Electric for modern power Advanced power distribution equipment created by the system. It is designed to meet the needs of power plant transmission, power system, and industrial and mining enterprise substations The goal is to meet the demand for power supply and distribution, with multiple functions such as control, protection, and frequent starting of high-voltage motors. The switchgear is designed strictly in accordance with the "five prevention" interlocking requirements, greatly reducing the risk of misoperation and ensuring the safety of equipment and personnel Employee safety. Extremely flexible in circuit breaker configuration, it can be equipped with ABB's VD4 vacuum circuit breaker The circuit breaker can also be selected from domestic VS1 vacuum circuit breakers, providing users with diverse choices.

• GB/T 3804 3.6KV~40.5KVHigh voltage AC load switch
• GB/T 1984 High voltage AC circuit breaker
• GB/T 16926 High voltage AC load switch fuse combination device
• GB/T 1985 High voltage AC isolation switch and grounding switch
• GB/T 3906 3.6KV~40.5KVExchange metal enclosed switchgear and control equipment
• GB/T 11022 Common technical requirements for high voltage switchgear and control equipment standards
• GB/T 4208 Protection level of shell (IP code)
• DL/T 404 3.6KV~40.5KVExchange metal enclosed switchgear and control equipment
• GB/T 311.1Insulation Coordination Part 1: Definition, Principles, and Planning
• DL/T 593 Common technical requirements for high voltage switchgear and control equipment standards
• DL/T 596 Preventive Testing Regulations for Power Equipment
• IEC 62271-200 AC metal enclosed switchgear and control equipment with rated voltage above 1KV and below 52KV

• Excellent protection: Metal armor provides strong protection against external objects, moisture and dust, ensuring internal safety and adapting to various environments.
• Exquisite structure: compact and pull-out design, saving space, convenient for maintenance and component replacement, flexible and practical.
• Reliable insulation: High quality insulation materials ensure good insulation between phases and relative to ground, withstand voltage surges, and operate stably.
• Operation safety: The operation structure is reliable, with interlocking to prevent misoperation, easy to operate, and ensures the safety of personnel and equipment.
