Environmentally friendly gas insulated circuit breaker cabinet

The SY-EG series environmentally friendly gas insulated ring main unit uses clean air as the insulating gas, This clean air is entirely composed of natural components in the atmosphere. Using 'clean air' can easily ensure stable operation of the switchgear throughout its entire lifecycle. This gas insulated switchgear is compact in structure, environmentally friendly, and maintenance free for life, with reliable operation, safe operation, and power supply The characteristic of high sustainability. Gas filled compartments for airtight laser welding ensure that high-pressure components are protected from external environmental influences, At the same time, prevent foreign objects from entering the cabinet. This series of switchgear has passed GB and IEC type tests, It is a three-phase metal enclosed, clean air insulated single busbar switchgear with parameters up to 12 kV, 20/25 kA, 630 A.

• Environmentally friendly, using eco-friendly insulation media
• Modular design, flexible solutions, clever expansion methods, and the ability to expand to any side
• Plug in design, quick installation, no gas operation required on site
• The operation interface is simple and easy to operate on site
• Power outage can replace any one without affecting other adjacent cabinets
• Complete interlocking and reliable anti internal arc design ensure the safety of operators
